The PDC bits
perfect for the clay from the sandstone over the clastic
hard rock drilling almost any soil type, quotation
request by email or phone. |
Step type 3
wings drag bit is suitable to drill through clay, marl,
loose grit, soft soil.
The bit is set of a short body and wings with vidia panels.
The number of stages, the number and size of vidia panels are decided
by the size of the drill bit.
Can
be ordered in any size.
See more pictures in the Gallery!
|
 Drill bit
with knot (Cobra type)
One of the most generally useable drill bit for drilling complete
segments. The crabs are
equipped with lenticular knots instead of cogs therefore
even the hardest quartzites can
be drilled through.
The so-called "cog cropes" are situated on the knots alternately so the
bit can clean itself. Self-cleaning is made possible by situating a cog
crope on one knot, while the knot next to it has no cog crope on the
same place.
See more pictures in the Gallery! |
Drill bit with
crab
One of the most generally useable drill bit for drilling complete
segments. The number, the size and the material of the cogs situated on
the crab decides which type of
rocks can be drilled with them.
The drill bits equipped with
the biggest size of cogs and the loosest set of cogs on
the crab are suitable to drill the softest
rocks (clay, marl, unbounded rocks, soft chalks etc),
smallest size of cogs and thickest set of cogs on the crab are suitable to drill hard rocks (hard
chalks, dry clay, dolomite etc).
Cog cropes are situated on the crabs alternately (cog crope is situated
on one crab, while the crab next to it has no cog crope on teh same
place) so the drill bit can
clean itself.
See more pictures in the Gallery! |
 Chevron
type 3 wings drag bit
The Chevron drill bits
are suitable to drill through clay, marl, loose grit, soft soil.
The bit is set of a short body and wings with vidia panels.
The number and size of vidia panels are decided by the size of the drill bit.
Can
be ordered in any size.
See more pictures in the Gallery! |
Diamond
drilling bits
Core bits is the cutting tools of rock
coring system.
According to the different raw materials and technology for segments,
there are impregnated diamond
core bits, surface set diamond core bits, Tungsten Carbide
(T.C) core bits and PDC Polycrystalline diamond core bits.
See more pictures in the Gallery!
|
Hammer bit for
fount drilling - various forms
This drill bit has to be gripped in special
hammer body.
Suitable to drill through the hardest rocks. Coated with industrial diamond or wolfram-carbid,
material of the bit is a very resistant
compound steel.
Surface and form can be various: number, size and other attributes of
drill spike can be changed. These drill bits are suitable to bear the most extreme
circumstances, therefore can be applied to drill through
the hardest rocks in any area.
See more pictures in the Gallery! |
Hammer body
for fount drilling
Hammer bodies are designed to grip hammer
drill bits. Can be ordered in various sizes and equipped with varoius terminals.
The size and terminal of the hammer body is decided by the size and
type of the hammer bit.
The function of the hammer body is to transmit the pressure of the air
between the machine and the drill bit.
The size of the hammer body
(weight, length, size of terminal) decides the type of the hammer.
See more pictures in the Gallery! |
